single-side woodworking planer

Brief: Suzhou Gaojing CNC Machinery Co.,Ltd is focused on selling wood working machinery for more than 6 years. We devoted ourselves to edge banding machine, drilling center, machining center. The following is about single-side woodworking planer , we hope to help you better understand of it.

Single-side woodworking planer professional solution: one-side planing for setting certain thickness, fit for finger joint factory, etc; improving the wood using ratio. Equipped with big diameter cutter spindle, four stand columns synchronously rise and fall; and equipped with bottom active roller on the workable and speed frequency control, ensuring the strong cutting and good processing quality.



Single-side woodworkig planer Product description

1. Max. working width630mm



Max. working width

630mm

Working thickness

3~300mm

Min. Working length

300mm

Feeding speed

5~18m/min

Max. Cutting depth

8mm

Cutter diameter

125mm

Spindle speed

5000r/min

Power   cutter motor

7.5kW

feeding motor

1.5kW

table lifting motor

0.37KW

Dust outlet dia

Φ150mm×

 Overall dimension(L*W*H)

115×130×152cm

Weight

1250Kg



This machine is with digital display for height, and with 4 screw rods for table lifting. Having one sectional in feed roller is in front of cutter.

Model MBZ106D-H with spiral cutter head, MBZ106D with straight blade cutter head.

Note: all above picture and parameter are subject to the real product. We reserve the right to improve our product.
