Automatic Single-chip Vertical Saw





BriefSuzhou Gaojing CNC Machinery Co.,Ltd is focused on selling wood working machinery for more than 6 years. We devoted ourselves to edge banding machine, drilling center, machining center. The following is about Automatic Single-chip Vertical Saw , we hope to help you better understand of it.







In order for operator safety, this Automatic Single-chip Vertical Saw

 is equipped with 4 sets of anti-kick back fingers, upper 3 and bottom 1. And it is with chain track feeding, the feeding speed change of it is by belt and pulley. Also we have other models: QMJ154F with frequency inverter for feeding speed change; QMJ154F-T with electric-lifting for pressure lifting. Please ask for the details.



Automatic Single-chip Vertical Saw

Max. cutting thickness

125m

Min. cutting length

300mm

Throat depth

510mm

Spindle dia

φ30mm

Spindle speed

3450r/min

Blade dia

300---400mm

Feeding speed

813.619.124m/min

Spindle power

11KW

Feeding motor

1.5KW

Table size

940×1700mm

Weight

1150Kg

Dimension

196×118×160cm
